Product Code

XY-802

Construction

(From outside to inside)

Glass Fiber Cord +Silicon Coated+ Glass Fabric+ Steel Wire+ Glass Fabric

Color

Red/black

InnerDiameter

40mm-300mm

(1.5"-12")

Thickness

0.6mm

Length

4m(Max)

Helix Spacing

15mm,16mm,18mm,19mm(customized)

Bending Property

Good

Helix Wire Diameter

1.2mm,1.5mm

Fiber Braiding Wire Thickness

1mm

Fire Resistance

Non-Flammable

Compression Ratio

Cannot Been Compressed

Temperature Range

-70℃/+280℃(short time to +310℃)

Operating Pressure

3000Pa

Maximum Air Velocity

30m/s

產品編碼

XY-802

材質

玻璃纖維繩+硅膠涂層玻纖布+ 鋼絲

顏色

紅色

內徑范圍

40mm-300mm

(1.5"-12")

管壁厚度

0.6mm

標準長度

4m(Max)

鋼絲間距

15mm,16mm,18mm,19mm(按要求定制)

彎曲性能

Good

鋼絲直徑

1.2mm,1.5mm

玻璃纖維繩直徑

1mm

阻燃性能

不可燃

壓縮比例

不可壓縮

溫度范圍

-70℃/+280℃(短期可達 +310℃)

最大壓力

3000Pa

最大風速

30m/s
